Aluminum Bar Gutter Wedge for Gutter Hanger - Available in colors
Available in Mill Finish or several Powder Coated Colors. For Hangers used with Half-Round Gutters, Box and K-Style Gutters
K&M's Gutter Wedge is manufactured from 3/16" aluminum bar stock. The dimensions and angles change along with the roof pitch in order to hang a gutter correctly.
A mounting hole is provided at the very top of the wedge and a optional hole is also provided at the back from sizes of pitch 3 and up.
This gutter wedge will work with most gutter hangers that can accept a 1/4" bolt for attachment through the back. It works
with our #15 half round gutter hanger and our
aluminum cross bar hanger.
Like our universal roof mounts and rafter mounts, our gutter wedge allows for 4.25" of total vertical pitch adjustments in 1/8" increments.
It comes with a 1/4" Stainless Steel bolt and locking nut.
Used on Aluminum gutters, steel gutters and galvalume gutters. Powder coated to match.
It is important to note that all dimensions and angles assume that the fascia board is perpendicular to the roof line, meaning it measures 90° off the roof. This
should always be the case when the fascia is angled, however, it may not be, so please double checking before ordering.
When a hidden hanger is used (as the crossbar hanger in the examples shown), a hole will need to be drilled in the back of the gutter
to attach the hanger to the gutter wedge with the provided bolt.
Measuring the pitch
The pitch or the angle of a roof is calculated by how many inches it rises vertically for every 12 inches it extends horizontally.
For example, a roof that rises 6 inches for every 12 inches of horizontal run is called a 6 pitch or a 6-12 pitch.
If drawn on a piece of paper, this triangle would have a 26.57° angle off the horizontal line (the wall line). A different example is a 12-12 pitch, where the rise is 12" over a 12" span,
creating a 45° angle. A flat roof would have a 0 pitch.
Specifications
Powder Coating Disclosure
Our colored gutter wedge bars are powder coated, which provides a very durable, long lasting finish. Be sure to order the correct pitch as these items are
manufactured from thick bar stock. There will be significant paint stretching in post powder coating bending, which will lead to some paint cracking / chipping.
To avoid any issues, we recommend that the correct roof bars be purchased pre bent to the correct roof pitch, and if not, that a can of
touch up spray paint be added to your order.
Submittals & Downloads
Color and Material Options
0.027" Aluminum Material Colors to Match
Black
Dark Bronze
Musket Brown
Royal Brown
Almond
Linen
Low Gloss White (30°)
High Gloss White (80°)
Pac Clad Standard 0.032" Kynar® Aluminum and 24 Gauge Galvalume Material Powder Coated Color Options to Match
Black Aluminum
Matte Black Steel
Charcoal Aluminum Steel
Dark Bronze Aluminum Steel
Medium Bronze Aluminum Steel
Copper Penny Aluminum Steel
Almond Aluminum Steel
Bone White Aluminum Steel
Atas Standard 0.032" Kynar® Aluminum and 24 Gauge Galvalume Material Powder Coated Color Options to Match
Black Aluminum Steel
Charcoal Grey Aluminum Steel
Classic Bronze (Dark Bronze) Aluminum Steel
Medium Bronze Aluminum Steel
Coppertone (Faux Copper) Aluminum Steel
Almond Aluminum Steel
Bone White Aluminum Steel
Common Material Options for Gutter Hangers
Mill Finish Aluminum
Other colors, materials and thickness may be available upon request. Colors displayed for reference only.
Please click here for a full selection of colors and materials offered.
