Hidden Mount 0.027" Aluminum Downspout Strap

Product SKU :

6.95 6.95 USD 6.95

6.95

/ ea
  • Color
  • Width
  • Depth

This combination does not exist.

ADD TO CART

Select Variant Min. Quantity Price per Unit

Terms and Conditions
30-day money-back guarantee
Lead Time: 7.0 Days

0.027" Aluminum Hidden Mount Strap for Plain Square or Round Downspout

Available Several colors. 0.027" Aluminum. Downspout wall attachment.

Downspout straps come pre formed to fit our standard plain square or round downspouts. This hanger is designed to get installed to the wall before you install your downspout and then the legs can be screwed or riveted into the side of the downspout. Can be used with our standard downspout strap. ***Select the 1 1/2" depth option if using in conjunction with our standard downspout strap.***

At least two downspout straps are required for every 10 feet of downspout. Three are usually sufficient for a straight 20' foot run.
For a 10 foot run, place a strap approximately 1' from the bottom and another 1' from the top. For a 20' foot run, use the same adding a strap right at the seam between the 2 downspouts, which also hides the seam giving it the appearance of a continuous length when used with our standard downspout strap.
Custom colors, sizes and materials are available. Please, contact us for a quote.

Downspout Size A / Width B / Leg C / Depth F / Stock Size
2"x3" / 3"x3" or 3" Round 3.25" 1.75" 1.5" or 2" 14"
3"x4" / 4"x4" or 4" Round 4.25" 2.75" 1.5" or 2" 19"
4"x5" / 5"x5" or 5" Round 5.25" 2.75" 1.5" or 2" 20"
Submittals & Downloads
Color and Material Options
0.027" Aluminum Downspout Strap Color Options
Black 0.027

Black

Dark bronze 0.027

Dark Bronze

Musket Brown 0.027

Musket Brown

Royal brown 0.027

Royal Brown

Almond 0.027

Almond

Linen 0.027

Linen

30° white 0.027

Low Gloss White (30°)

80° white 0.027

High Gloss White (80°)

Other colors, materials and thickness may be available upon request. Colors displayed for reference only.
Please click here for a full selection of colors and materials offered.
